Dell 405-ABCT PERC H355 RAID-ohjain PCIe 4.0 x8 12Gbps SAS/SATA Low Profile

The Dell 405-ABCT PERC H355 is a high-performance RAID controller designed for Dell PowerEdge 15th Generation servers. It provides reliable data protection and enhanced storage performance for enterprise environments.

Advantages

Supports RAID levels 0, 1, 5, 10, and 50 for flexible data redundancy and performance optimization. With PCI Express 4.0 x8 interface, it delivers high bandwidth for demanding workloads. The controller supports SAS and SATA drives, including SSDs, and offers data transfer rates up to 12 Gbps for SAS and 6 Gbps for SATA.

Suitable for

• Dell PowerEdge 15th Generation servers
• Enterprise data centers requiring reliable RAID solutions
• Applications needing high-speed storage connectivity

Key specifications

• Controller Type: RAID Controller (Host-based)
• Host Interface: PCI Express 4.0 x8
• Internal Connectors: 2 x Mini-SAS HD (SFF-8643)
• Internal Ports: 8
• Data Transfer Rate: 12 Gbps SAS / 6 Gbps SATA
• RAID Levels: 0, 1, 5, 10, 50
• Supported Drive Types: SAS, SATA
• Supported Drive Form Factors: HDD, SSD
• Form Factor: Low Profile (PCIe adapter)
• Cache Memory: No Cache (Host-based RAID)
• Controller Processor: Broadcom SAS3808
• Maximum Logical Drives: 64
• Maximum Physical Drives: 8 (direct connect)
• Operating System Support: Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
• Management Software: Dell OpenManage Storage Management
• Bracket Included: Low-profile and Full-height bracket

Recommendations

For optimal performance, use with Dell PowerEdge servers and compatible SAS/SATA drives. Ensure firmware is updated to the latest version for best compatibility.
