EFB Elektronik E-HDS 26 LL/Z juotosliitäntä DB-26 uros

The EFB Elektronik E-HDS 26 LL/Z Solder Connector is a high-quality D-Sub High-Density connector designed for reliable serial connections. This DB-26 male plug features solder cup termination for secure and durable wiring, making it ideal for industrial and commercial applications where robust connectivity is essential.

Advantages

Gold flash over nickel contacts ensure excellent conductivity and corrosion resistance. The nickel-plated steel shell provides durability and EMI shielding. RoHS compliant and rated for 1 A per contact, this connector meets stringent quality standards.

Suitable for

• Serial communication interfaces requiring DB-26 connections
• Industrial automation and control systems
• Data transmission equipment
• Custom cable assemblies

Key specifications

• Connector Type: D-Sub High-Density
• Gender: Male (Plug)
• Number of Positions: 26
• Termination Style: Solder Cup
• Mounting Type: Cable Mount
• Shell Material: Steel, Nickel Plated
• Contact Material: Copper Alloy, Gold Flash over Nickel
• Insulator Material: PBT (Polybutylene Terephthalate)
• Flammability Rating: UL94V-0
• Current Rating: 1 A per contact
• Voltage Rating: 250 V AC
• Operating Temperature: -55°C to +105°C
• Mating Cycles: 50
• Dielectric Withstanding Voltage: 1000 V AC (1 min)
• Insulation Resistance: >1000 MΩ
• RoHS Compliant

Recommendations

For optimal performance, use with matching DB-26 female connectors and ensure proper soldering technique. Suitable for cable mounting in controlled environments.
