JUNG MA A 1122 WW USB 2.0 -istukka, termoplasti, sarja AS/A, alppivalkoinen

Charge two devices at once with a total output of 2.4 A from this flush-mounted USB charging insert. It delivers 5 V DC via two USB Type-A ports, drawing power from a 230 V AC mains connection.

Overview

The JUNG MAA1122WW is a USB charging insert designed for integration into JUNG switch ranges including AS 500, A 500, A creation, A plus, CD 500, CD plus, LS 990, LS design, LS plus, and SL 500. The insert is finished in Alpine White and made of thermoplastic.

What stands out

• Two USB Type-A ports with a combined 2.4 A output
• Flush-mounted installation with screw terminals
• Standby power consumption below 0.1 W
• Short-circuit, overload, and overheating protection

Technical details

• Output voltage: 5 V DC
• Total output current: 2.4 A
• Input voltage: 230 V AC, 50/60 Hz
• Protection class: IP20
• Operating temperature: 0 °C to +45 °C
• Material: Thermoplastic
• Colour: Alpine White

Our verdict

A reliable in-wall USB charging solution for JUNG switch systems, offering dual-port charging with essential safety features in a clean white finish.
