RUKO FRS-DIN8033-HM-TiAlN Ø16,0mm VHM-varrenjyrsin

Precision-ground solid carbide end mill with TiAlN coating, engineered for high-performance machining of steel, stainless steel, and cast iron. The 16.0 mm cutting diameter and 35° helix angle deliver excellent chip evacuation and surface finish in slotting, profiling, and plunging operations.

Overview

This end mill is manufactured to DIN 8033 standards, ensuring consistent geometry and performance. The TiAlN coating provides high hardness and oxidation resistance up to 800°C, enabling dry machining and extended tool life. The h6 shank tolerance ensures precise clamping in standard collets, while the h10 cutting diameter tolerance guarantees accurate part dimensions.

What stands out

• TiAlN coating for high-temperature performance and reduced friction
• Solid carbide construction for rigidity and wear resistance
• 4-flute design for balanced chip load and smooth cutting
• Polished flutes improve chip flow and prevent built-up edge
• Precision ground for tight tolerances and repeatability

Technical details

• Cutting diameter: 16.0 mm
• Shank diameter: 16.0 mm
• Overall length: 92 mm
• Flute length: 32 mm
• Helix angle: 35°
• Number of flutes: 4
• Shank tolerance: h6
• Cutting diameter tolerance: h10
• Coating: TiAlN
• Standard: DIN 8033
• Material: Solid carbide

Our verdict

A robust end mill for demanding metalworking tasks, offering excellent wear resistance and precision for general-purpose machining.
