RUKO sovitinruuvi M12 nikkelöity messinki kuusikulmainen

With a 1 mm thread pitch and M12 thread, this adapter screw is built for precise connections in M12 connectors and panel feed-throughs. The nickel-plated brass body provides reliable conductivity and corrosion resistance.

Overview

The RUKO GMBH Adapter Screw M12 is a precision component designed for industrial connectivity. Its hexagonal head allows for easy installation with a 14 mm wrench, and the 12 mm thread length ensures secure engagement.

What stands out

• Nickel-plated brass construction for durability and conductivity
• Hexagonal head with 14 mm wrench size for easy tightening
• Operating temperature range from -40 °C to 85 °C for harsh environments
• IP67 protection when properly installed, suitable for demanding applications

Technical details

• Thread type: M12
• Thread pitch: 1 mm
• Thread length: 12 mm
• Overall length: 16 mm
• Material: Brass (CuZn)
• Surface treatment: Nickel-plated
• Head type: Hexagonal
• Wrench size: 14 mm
• Tightening torque: 0.8 Nm
• Operating temperature: -40 °C to 85 °C
• IP protection rating: IP67 (when properly installed)
• RoHS compliant: Yes
• REACH compliant: Yes

Our verdict

A robust adapter screw for M12 connector systems, offering reliable performance in a wide range of industrial environments.
