Tilt Integrated ohjainlaakerisarja (Silver)

The Tilt Integrated Headset (Silver) is a high-performance integrated headset designed for modern road, mountain, and gravel bikes. Engineered with precision CNC machined aluminum and sealed cartridge bearings, it delivers smooth steering and long-lasting durability. The anodized silver finish adds a sleek, professional look to any build.

Advantages

This headset features a tapered steerer tube compatibility (1-1/8" to 1.5") and fits frames with IS42/IS52 integrated head tubes. The 45° x 45° bearing angle ensures optimal load distribution, while the sealed cartridge bearings protect against dirt and moisture. The included components—top cap, compression ring, split ring, upper bearing, lower bearing, and crown race—provide everything needed for a complete installation.

Suitable for

• Road bikes
• Mountain bikes
• Gravel bikes
• Frames with IS42/IS52 integrated head tube
• Forks with 1-1/8" to 1.5" tapered steerer

Key specifications

• Headset Type: Integrated (IS - Integrated Standard)
• Steerer Tube Compatibility: Tapered 1-1/8" to 1.5"
• SHIS Upper Code: IS42/28.6
• SHIS Lower Code: IS52/40
• Upper Bearing Outer Diameter: 41.8 mm
• Lower Bearing Outer Diameter: 52 mm
• Bearing Angle: 45° x 45°
• Bearing Type: Sealed Cartridge Bearings
• Bearing Material: High-grade Steel
• Crown Race Diameter: 40 mm
• Top Cap Material: CNC Machined Aluminum
• Color: Silver
• Stack Height: 9.5 mm
• Weight (approx.): 125 g
• Finish: Anodized

Recommendations

For best performance, ensure your frame and fork are compatible with the IS42/IS52 standard and tapered steerer. Professional installation is recommended to guarantee proper bearing preload and alignment.
