2-Power pääakkupaketti - akku - 80 mAh (2P-5B10W13900)

With a capacity of 80 mAh and a voltage of 3.7 V, this 2-Power battery pack delivers dependable power for small electronic devices, IoT sensors, and wearables. Its integrated protection circuit module guards against overcharge, over-discharge, and short circuits, ensuring safe and long-lasting operation.

Overview

The 2-Power 2P-5B10W13900 is a rechargeable lithium-ion battery pack engineered for compact applications where space and reliability are critical. It features a single prismatic/pouch cell with a nominal voltage of 3.7 V and an energy rating of 0.296 Wh. The battery supports up to 500 charge/discharge cycles, making it a cost-effective power solution for embedded systems and portable electronics.

What stands out

• Integrated PCM for overcharge, over-discharge, and short-circuit protection
• Wide operating temperature range from -20°C to 60°C
• CE and RoHS certified for safety and environmental compliance
• Compact prismatic/pouch form factor ideal for space-constrained designs
• Supports 1C discharge (80 mA) and 0.5C charge (40 mA) rates

Technical details

• Battery Type: Lithium-ion (Li-ion)
• Capacity: 80 mAh
• Voltage: 3.7 V
• Energy: 0.296 Wh
• Number of Cells: 1
• Connector Type: Varies (e.g., 2-pin JST, solder tabs)
• Max Discharge Current: 80 mA (1C)
• Max Charge Current: 40 mA (0.5C)
• Cycle Life: 300-500 cycles
• Operating Temperature: -20°C to 60°C
• Storage Temperature: -20°C to 45°C
• Certifications: CE, RoHS

Our verdict

A rugged and reliable power source for miniature electronics, the 2-Power 2P-5B10W13900 combines essential safety features with consistent performance, making it a smart choice for developers and OEMs.
