ZUBEHÖR kuusiokoloruuvi M10x40 mm DIN 912 teräs 8.8 30001187

When a standard bolt is too bulky or a hex head would snag on moving parts, you need a fastener that sits flush and transfers torque reliably. The ACCESSORY M10x40mm hexagon socket head cap screw solves that with a cylindrical head that fits into counterbored holes, driven by an 8 mm Allen key for a clean, secure assembly.

Who is it for

Maintenance technicians, machine builders, and anyone assembling equipment where a low-profile, high-strength joint is essential. If you work with metric machinery, jigs, or fixtures, this screw gives you the clamping force of a grade 8.8 bolt without the protruding head.

Main features

• Metric M10 coarse thread (1.5 mm pitch) for standard tapped holes
• 40 mm thread length, 50 mm overall length
• Steel grade 8.8 for high tensile strength
• Hex socket drive (8 mm) for high torque without cam-out
• DIN 912 / ISO 4762 dimensional standard
• Plain finish, right-hand thread

Specifications

• Fastener type: Hexagon socket head cap screw
• Nominal diameter: M10
• Thread pitch: 1.5 mm
• Length under head: 40 mm
• Overall length: 50 mm
• Head diameter: 16 mm
• Head height: 10 mm
• Drive size: 8 mm hex socket
• Material: Steel
• Material grade: 8.8
• Finish: Plain / black oxide
• Thread direction: Right-hand
• Standard: DIN 912 / ISO 4762

Tips

Use a quality 8 mm hex bit and clean the threads before installation. For outdoor or corrosive environments, consider a coated variant—plain steel offers low corrosion resistance.
