ACT SC kuituvaimennin 5 dB yksimuoto SC/UPC metallikotelo EA4005

In fiber optic networks, excessive optical power can saturate receivers and degrade signal quality. The ACT SC Fiber Optic Attenuator 5 dB solves this by precisely reducing signal strength by 5 dB, ensuring optimal performance in single-mode systems.

Who is it for

Network engineers and technicians working with SC/UPC single-mode fiber links who need to balance optical power levels in telecom, CATV, or data center environments.

Main features

• Fixed 5 dB attenuation with ±0.5 dB tolerance for consistent signal reduction.
• SC/UPC connector compatible with standard single-mode fiber interfaces.
• Durable nickel-plated brass housing for reliable mating over 1000 cycles.
• Wide operating temperature range from -40°C to +75°C.
• Low polarization dependent loss (≤0.2 dB) and high return loss (≥50 dB).

Specifications

• Attenuation Level: 5 dB
• Connector Type: SC/UPC
• Fiber Mode: Single-mode
• Operating Wavelength: 1310nm / 1550nm
• Attenuation Tolerance: ±0.5 dB
• Return Loss: ≥50 dB
• Polarization Dependent Loss (PDL): ≤0.2 dB
• Maximum Optical Power: 200 mW (+23 dBm)
• Operating Temperature: -40°C to +75°C
• Storage Temperature: -40°C to +85°C
• Mating Durability: >1000 cycles
• Housing Material: Metal (Nickel-plated Brass)
• Compliance: RoHS

Tips

Use this attenuator to prevent receiver overload in short fiber links or when testing high-power transmitters. Ensure connectors are clean before installation to maintain signal integrity.
