ALLNET ALL-BRICK-0013 transistori 2 NPN Switching Module

The ALLNET ALL-BRICK-0013 Transistor 2 is a compact NPN bipolar junction transistor (BJT) switching module designed for electronic switching and digital control applications. Part of the ALL-BRICK system, it provides a convenient breadboard-friendly interface for driving low-power loads such as LEDs, small relays, buzzers, and logic level shifting.

Advantages

This module simplifies prototyping by integrating a pre-biased NPN transistor with a 3-pin header (VCC, GND, Signal). It operates at logic-level input voltages (3.3V-5V DC) and can switch up to 30V DC at 100mA, making it ideal for microcontroller projects with Arduino, Raspberry Pi, and similar boards. The TO-92 package ensures reliable performance across a wide temperature range (-40°C to +85°C).

Suitable for

• Driving LEDs and indicator lights
• Controlling small relays and buzzers
• Low-power motor control
• Logic level conversion (3.3V to 5V or vice versa)
• Educational electronics and prototyping

Key specifications

• Module Type: Transistor Switching Module
• Transistor Type: NPN Bipolar Junction Transistor (BJT)
• Number of Transistors: 1
• Input Control Voltage: 3.3V - 5V DC (Logic Level)
• Max Collector-Emitter Voltage (Vce): 30V DC
• Max Collector Current (Ic): 100mA
• Max Power Dissipation (Pd): 500mW
• DC Current Gain (hFE): 100 - 800
• Connector Interface: 3-pin Header (VCC, GND, Signal)
• Mounting Type: Breadboard-friendly / PCB Mount
• Operating Temperature Range: -40°C to +85°C

Recommendations

For best results, use with a base resistor if driving directly from a microcontroller pin. Ensure the load does not exceed the maximum ratings. Compatible with ALLNET ALL-BRICK system and standard breadboards.
