APC GVAE20 Basic PDU 20A 0U pystysuuntainen virranjakoyksikkö, 12x C13 + 4x C19, musta

The APC GVAE20 is a reliable and cost-effective basic power distribution unit (PDU) designed for data centers, server rooms, and network cabinets. It provides efficient power distribution without monitoring or switching capabilities, ensuring continuous power delivery to connected equipment. With a vertical 0U form factor, it mounts easily on the side of a rack, saving valuable rack space.

Advantages

This PDU offers a high power capacity of 3328 VA / 3328 W, supporting demanding IT loads. It features a mix of 12 IEC C13 and 4 IEC C19 outlets, accommodating various server and network device plugs. The 3.05-meter (10-foot) input cord with NEMA L6-20P plug provides flexibility in installation. Its rugged metal construction ensures durability in professional environments.

Suitable for

• Data centers requiring basic power distribution
• Server racks with mixed C13 and C19 equipment
• Network cabinets needing vertical mounting
• IT professionals seeking a cost-effective PDU solution

Key specifications

• PDU Type: Basic (Unmanaged)
• Input Voltage: 200V, 208V, 230V
• Input Frequency: 50/60 Hz
• Input Connection: NEMA L6-20P
• Nominal Input Current: 20A
• Output Voltage: 208V
• Output Connections: (12) IEC 320 C13, (4) IEC 320 C19
• Power Capacity: 3328 VA / 3328 W
• Cord Length: 3.05 m (10 ft)
• Rack Height: 0U
• Mounting Type: Vertical
• Color: Black
• Overload Protection: No
• Phase: Single Phase
• Operating Temperature: 0 - 45 °C
• Operating Relative Humidity: 0 - 95 %
• Approvals: CSA, UL Listed

Recommendations

For optimal performance, ensure the PDU is connected to a dedicated 20A circuit. This unit is ideal for environments where basic power distribution is sufficient and advanced monitoring is not required.
