B-TECH seinäteline 200x200mm E-paper-näytölle - valkoinen

The B-TECH Wall Mount 200x200mm is a secure, fixed wall mount designed for E-Paper displays and monitors up to 43 inches. With a slim 15mm profile and a robust steel construction, it provides a clean, professional installation. The mount features a 'hook-on' mechanism with security screws to prevent accidental dismounting, making it ideal for public or commercial environments.

Advantages

Ultra-low profile (15mm) for a sleek, space-saving installation. Integrated spirit level ensures quick and accurate alignment. Security screws provide tamper-resistant mounting, ideal for retail, education, or corporate settings. Supports VESA patterns 75x75mm to 200x200mm, offering broad compatibility.

Suitable for

• E-Paper displays and monitors from 23 to 43 inches
• Digital signage in retail, hospitality, and public spaces
• Secure installations where accidental dismounting must be prevented
• Wall mounting with VESA 75x75, 100x100, 200x100, or 200x200mm patterns

Key specifications

• Mount Type: Fixed Wall Mount
• Screen Size Compatibility: 23" - 42"
• Maximum Load Capacity: 25 kg (55 lbs)
• VESA Compatibility: 75x75mm, 100x100mm, 200x100mm, 200x200mm
• Profile from Wall: 15 mm (0.6")
• Material: Steel
• Colour: White
• Number of Screens Supported: 1
• Installation Method: 'Hook-on' with security screws
• Integrated Spirit Level: Yes
• Screen Orientation: Landscape
• Wall Plate Dimensions: 220 x 220 mm
• Finish: Powder Coated
• Mounting Hardware: Included

Recommendations

For optimal security, ensure the mount is attached to a solid wall capable of supporting the combined weight of the mount and display. Use the included security screws to lock the display in place. This mount is not suitable for ceiling or pole installations.
