BATTERY TECH akkulaturi Orion XS 1400

The BATTERY TECH Orion XS 1400 is a high-performance, fully automatic battery charger designed for professional and recreational use. With a maximum output current of 140 A and power of 1680 W, it efficiently charges lead-acid and LiFePO4 batteries. Its compact, fanless design and IP65 rating make it suitable for harsh environments.

Advantages

Ultra-high efficiency up to 98.5% reduces energy loss. Bluetooth Smart and VE.Direct communication enable remote monitoring and control. Unlimited parallel capability allows scalability for larger battery banks. Smart alternator compatibility ensures safe charging in vehicles.

Suitable for

• Marine and RV battery systems
• Off-grid solar installations
• Commercial vehicle fleets
• Emergency backup power systems

Key specifications

• Input Voltage: 8–17 VDC
• Output Voltage: Adjustable 10–17 VDC (default 12.2 VDC)
• Max Output Current: 140 A
• Max Output Power: 1680 W
• Efficiency: Up to 98.5%
• Topology: Synchronous Buck-Boost
• Protection: Short circuit, over temperature, input over/under voltage, output over voltage, reverse polarity
• Communication: Bluetooth Smart, VE.Direct
• IP Rating: IP65
• Operating Temperature: -40 to +60°C (full power up to 40°C)
• Battery Compatibility: Lead-acid (AGM, GEL, Flooded), LiFePO4
• Charging Algorithm: Adaptive 3-stage (Bulk, Absorption, Float)
• Cooling: Fanless
• Parallel Capability: Yes, unlimited units
• Remote On/Off: Yes
• Dynamic Current Limiter: Yes
• Smart Alternator Compatibility: Yes
• Warranty: 5 years

Recommendations

For optimal performance, use with compatible batteries and ensure proper ventilation. The charger is designed for indoor and outdoor use but should be protected from direct water immersion.
