BlueOptics SC-UPC yksimuotokuituinen vaimennin 8dB

The BlueOptics SC-UPC Singlemode Fiber Optic Attenuator provides precise 8dB attenuation for singlemode fiber networks operating in the 1270nm to 1610nm wavelength range. Designed with a ceramic ferrule and UPC polish, it ensures low insertion loss and high return loss for reliable signal management.

Advantages

High-quality ceramic ferrule ensures durability and stable performance. UPC polish minimizes back reflection, making it ideal for high-speed networks. Wide operating temperature range (-40°C to +75°C) suits harsh environments.

Suitable for

• Singlemode fiber optic systems requiring precise attenuation
• Telecommunications, CATV, and data center applications
• Testing and measurement setups

Key specifications

• Connector type: SC-UPC Simplex
• Attenuation: 8 dB
• Wavelength range: 1270 nm - 1610 nm
• Return loss: > 45 dB
• Insertion loss: < 0.1 dB
• Ferrule material: Ceramic
• Operating temperature: -40°C to +75°C

Recommendations

For optimal performance, use with singlemode patch cables and ensure clean connections. Ideal for balancing signal levels in fiber optic links.
