Bopla Combinorm kotelo 100 x 75 x 109,5 mm ABS vaaleanharmaa RAL 7035 CN 100 AK 65010010.H

The Bopla Combinorm CN 100 AK enclosure offers a robust housing solution for electronics in industrial and measurement applications. Its light grey ABS body (RAL 7035) provides a clean, professional appearance while maintaining durability. With external dimensions of 100 x 75 x 109.5 mm, it accommodates a variety of PCBs and components, and integrated mounting bosses simplify assembly.

Highlights

• Material: ABS (Acrylonitrile Butadiene Styrene), light grey RAL 7035
• External dimensions: 100 mm length, 75 mm width, 109.5 mm height
• IP65 ingress protection for dust and water jets
• Impact resistance: IK07
• Lid fastened with stainless steel screws
• Operating temperature range: -40 to +80 °C
• Flammability rating: UL 94 HB
• Integrated mounting bosses for PCBs or plates

In daily use

This enclosure is suitable for general-purpose electronics, industrial control units, and measurement technology. The ABS material offers a good balance of impact resistance and surface quality. The light grey color blends well in control cabinets and on machinery. The stainless steel lid screws ensure secure closure and repeated access without corrosion.

Full specifications

• Series: Combinorm
• Product type: Electronics enclosure
• Material: ABS
• Colour: Light grey (RAL 7035)
• External length: 100 mm
• External width: 75 mm
• External height: 109.5 mm
• IP rating: IP65
• Impact resistance: IK07
• Lid fastening: Stainless steel screws
• Operating temperature: -40 to +80 °C
• Flammability rating: UL 94 HB
• Internal mounting: Integrated mounting bosses for PCBs/plates
• Number of units: 1
• Application: General purpose electronics, industrial control, measurement technology

Final note

A reliable enclosure for demanding environments, offering protection and easy integration.
