Cimco 187601 johdinpääteholkkisarja, osittain eristetty, 1250 kpl, DIN 46228-4

Professional ferrule assortment with 1250 partially insulated wire ferrules in a robust plastic box. Colour-coded to DIN 46228 Part 4 for quick cross-section identification and reliable connections in control cabinet wiring.

Advantages

Tin-plated electrolytic copper sleeves with polypropylene insulation collars ensure secure crimping and strain relief. The DIN colour code simplifies selection: orange (0.5 mm²), white (0.75 mm²), yellow (1.0 mm²), red (1.5 mm²), blue (2.5 mm²), grey (4.0 mm²), black (6.0 mm²), ivory (10.0 mm²).

Suitable for

• Professional electrical wiring
• Control cabinet construction
• Panel building and switchgear assembly

Key specifications

• Type: Ferrule assortment
• Insulation: Partially insulated
• Sleeve material: Tin-plated electrolytic copper
• Insulation material: Polypropylene (PP)
• Standard: DIN 46228 Part 4
• Total quantity: 1250 pieces
• Cross-sections: 0.5, 0.75, 1.0, 1.5, 2.5, 4.0, 6.0, 10.0 mm²
• Max operating temperature: 105°C

Recommendations

Use with appropriate crimping pliers for ferrules to achieve a gas-tight connection. Store in the supplied assortment box for organised access on site.
