CipherLab 8600 UHF RFID Snap-on-moduuli

Warehouse and field-service teams using CipherLab 8600 Series mobile computers can add UHF RFID reading by snapping on this module. It reads EPC Class 1 Gen 2 / ISO 18000-6C tags in the 865-868 MHz ETSI band through an integrated circular polarized antenna, with a typical read range up to 1 meter. The module draws power from the host device and includes LED status indicators. Operating temperature range is -20°C to 50°C, storage -30°C to 70°C, humidity 5% to 95% RH non-condensing. It inherits the host device's IP rating, typically IP65.

Key specifications

• RFID frequency: UHF 865-868 MHz (ETSI)
• RFID protocol: EPC Class 1 Gen 2, ISO 18000-6C
• Antenna: integrated circular polarized
• Read range: up to 1 meter
• Connection: direct snap-on to CipherLab 8600 Series
• Power: from host device
• Operating temperature: -20°C to 50°C
• Storage temperature: -30°C to 70°C
• Humidity: 5% to 95% RH non-condensing
• Indicators: LED status

Why choose it

Adds UHF RFID capability without replacing existing CipherLab 8600 devices. The snap-on design keeps the setup compact and powered by the host, avoiding extra batteries or cables.

Ideal use cases

• Inventory counts in retail backrooms
• Asset tracking in warehouses
• Supply chain receiving and dispatch

Good to know

The module works only with CipherLab 8600 Series mobile computers. It does not include a separate power source.
