COMNET SFP-26A SFP-moduuli 100BASE-FX 1310nm monimuoto 2km SC-liitin MSA-yhteensopiva

The COMNET SFP-26A is a high-performance SFP (Small Form-Factor Pluggable) transceiver module designed for 100BASE-FX applications over multi-mode fiber. It operates at a wavelength of 1310 nm and supports a maximum transfer distance of 2 km (1.2 miles). This module is MSA compliant and features a duplex LC connector, ensuring compatibility with a wide range of networking equipment from leading vendors such as Cisco, HP, Juniper, Arista, and Dell.

Advantages

Hot-swappable design allows for easy installation and replacement without network downtime. Supports Digital Diagnostic Monitoring (DDM/DOM) for real-time performance monitoring. Low power consumption of less than 1 W reduces energy costs. Durable zinc alloy housing ensures long-lasting reliability.

Suitable for

• Enterprise network upgrades and expansions
• Data center interconnections
• Telecommunications and service provider networks
• Industrial and commercial Ethernet networks

Key specifications

• Module Type: SFP
• Data Rate: 100 Mbps
• Ethernet Standard: 100BASE-FX
• Wavelength: 1310 nm
• Fiber Type: Multi-mode (MMF)
• Connector Type: Duplex LC
• Max Transfer Distance: 2 km (1.2 miles)
• DDM/DOM Support: Yes
• Hot Swappable: Yes
• MSA Compliant: Yes
• Industry Standards: IEEE 802.3u
• Operating Temperature: 0°C to 70°C (32°F to 158°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Power Consumption: < 1 W
• Duplex Mode: Full Duplex
• Fiber Core Size Compatibility: 50/125 µm, 62.5/125 µm
• Compatibility: Vendor Agnostic
• Housing Material: Zinc Alloy
• MTBF: 3,000,000 hours

Recommendations

For optimal performance, pair the COMNET SFP-26A with high-quality multi-mode fiber patch cables and compatible switches or routers. Ensure proper handling and storage within specified temperature ranges to maximize lifespan.
