Datalogic CAB-GD05 - anturikaapeli - 17-napainen M12

Engineered for demanding industrial environments, this 5-meter sensor connection cable ensures reliable data transmission with a 17-pin M12 male connector and a shielded PVC jacket. The straight M12 connector mates to IP67-rated interfaces, sealing out dust and moisture, while the free end (pigtail) offers flexible wiring options for custom installations. Operating from -25°C to 80°C, it handles 30V and 1.5A per pin, making it a robust link for automation and data acquisition systems.

Overview

The Datalogic CAB-GD05 is a sensor connection cable designed to bridge M12-equipped sensors and actuators to control systems. Its 17-pin configuration supports complex signal and power requirements, common in industrial automation. The cable features a male M12 connector on one end and a free end (pigtail) on the other, allowing termination according to application needs. With a length of 5 meters, it provides ample reach for machinery and panel connections. The PVC jacket is durable and resistant to oils and chemicals typically found in industrial settings, while the overall shielding minimizes electromagnetic interference, ensuring signal integrity.

What stands out

• 17-pin M12 male connector with straight orientation for secure, vibration-resistant mating.
• 5-meter length offers flexibility in positioning sensors and controllers.
• Shielded PVC jacket protects against EMI and mechanical stress.
• IP67 rating when mated ensures protection against dust and temporary immersion.
• Wide operating temperature range from -25°C to 80°C suits harsh environments.
• Compliant with RoHS and CE standards for safety and environmental responsibility.

Technical details

• Connector 1: M12, male, 17-pin, straight
• Connector 2: Free end (pigtail)
• Cable length: 5 m
• Jacket material: PVC
• Shielding: Shielded
• Cable color: Black
• Operating temperature: -25°C to 80°C
• Voltage rating: 30V
• Current rating: 1.5A per pin
• IP rating (mated): IP67
• Application: Industrial automation, sensor connectivity, data acquisition
• Compliance: RoHS, CE

Our verdict

For reliable sensor connectivity in industrial environments, the Datalogic CAB-GD05 delivers the performance and durability needed. Its 17-pin M12 design and shielded construction make it a solid choice for automation professionals seeking a dependable connection solution.
