dBTechnologies LVX P15 passiivinen pylväskaiutin 15 tuumaa

The dBTechnologies LVX P15 is a high-performance 2-way passive column loudspeaker designed for professional audio applications. Featuring a 15-inch woofer and a 1-inch compression driver, it delivers powerful and clear sound with a maximum SPL of 127 dB. The plywood enclosure with full metal grille ensures durability, while the 36 mm pole mount and 12x M8 rigging points offer flexible installation options.

Advantages

Exceptional sound quality with wide frequency response (59-20,000 Hz) and controlled dispersion (90° x 70°). Robust construction and versatile mounting options make it ideal for both fixed installations and portable use.

Suitable for

• Live sound reinforcement
• PA systems for events and venues
• Fixed installations in clubs, theaters, and houses of worship
• Portable sound systems

Key specifications

• Speaker Type: 2-Way Passive Loudspeaker
• Woofer: 15" (381 mm) with 2.5" voice coil
• Tweeter: 1" (25.4 mm) compression driver
• Power Handling: 400 W RMS / 800 W Peak
• Impedance: 8 Ohm
• Frequency Response: 59-20,000 Hz (-10 dB) / 70-19,000 Hz (-3 dB)
• Max SPL: 127 dB
• Dispersion: 90° x 70°
• Crossover Frequency: 1800 Hz
• Input Connectors: 2x Speakon NL4 (Input/Link)
• Enclosure: Plywood with full metal grille
• Mounting: 36 mm pole mount, 12x M8 rigging points
• Handles: 2x side handles

Recommendations

For optimal performance, pair the LVX P15 with an amplifier delivering 400W RMS at 8 Ohms. Use Speakon NL4 cables for reliable connectivity.
