Eaton 207537 3-napainen kiertokytkin, 20 A, 690 V, etuasennus, musta/valkoinen

Rated at 20 A and 690 V, this Eaton 207537 rotary switch provides robust ON-OFF control for industrial applications. Its 3-pole design and front mounting make it suitable for panel installation, while the black handle and white front plate with clear ON-OFF markings ensure easy operation.

Overview

The Eaton 207537 is a main switch with a rotary actuator, engineered for reliable circuit isolation. It features screw terminals and a 90° switching angle, with two positions: ON and OFF. The switch meets the demands of industrial control panels and machinery, offering a compact 48 x 48 mm front plate.

What stands out

• High rated operational current of 20 A at 500 V AC-21A
• Rated insulation voltage up to 690 V
• Front protection degree IP65, terminals IP20
• Short-circuit withstand current 320 A (1s)
• Compact front plate 48 x 48 mm

Technical details

• Switch type: Main switch / Rotary switch
• Function: ON-OFF
• Number of poles: 3
• Mounting type: Front mounting
• Handle colour: Black
• Front plate colour/marking: White with ON-OFF
• Rated operational current (Ie) AC-21A: 20 A at 500 V
• Rated insulation voltage (Ui): 690 V
• Rated impulse withstand voltage (Uimp): 6 kV
• Rated operational voltage (Ue): 690 V
• Rated short-circuit withstand current (Icw): 320 A (1s)
• Rated conditional short-circuit current: 6 kA
• Degree of protection (front): IP65
• Degree of protection (terminals): IP20
• Switching angle: 90°
• Number of switching positions: 2 (ON, OFF)
• Terminal type: Screw terminals
• Standards: IEC/EN 60947, VDE 0660
• Approvals: CE, UL, CSA, CCC
• Front plate dimensions: 48 x 48 mm

Our verdict

A dependable rotary switch for industrial power control, offering high ratings and clear visual status in a space-saving design.
