Eaton 281191 liitinhyppy ZB2.5 riviliittimille, 10-napainen, 24 A, 800 V, harmaa

Rated for 24 A and 800 V, this 10-pole plug-in bridge distributes potential across Eaton ZB2.5 series terminal blocks with a 5.2 mm pitch.

Overview

The Eaton 281191 is a grey plug-in bridge (jumper) designed for cross-connection and potential distribution in terminal block assemblies. It plugs directly into compatible ZB2.5 series terminal blocks, creating a reliable 10-way link without tools.

What stands out

• 10-pole configuration for efficient multi-point bridging
• High current rating of 24 A and voltage rating of 800 V
• Compact 5.2 mm pitch matches ZB2.5 terminal block spacing
• Polyamide insulation with UL 94 V-0 flammability rating
• Operating temperature range from -25 to +100 °C

Technical details

• Accessory type: Plug-in bridge / Jumper
• Number of poles: 10
• Rated current: 24 A
• Rated voltage: 800 V
• Compatible terminal block cross-section: 2.5 mm²
• Pitch / Grid dimension: 5.2 mm
• Insulation material: Polyamide (PA)
• Colour: Grey
• Connection method: Plug-in
• Function: Cross-connection / Potential distribution
• Series compatibility: Eaton ZB2.5 series terminal blocks
• Mounting type: Direct plug-in
• Flammability rating: UL 94 V-0
• Operating temperature range: -25 to +100 °C
• Number of connections: 10

Our verdict

A robust and efficient solution for potential distribution in industrial terminal block assemblies, offering high ratings and easy installation.
