Eaton M22 litteä painonappikäyttö, vihreä, hetkellinen, 22,5 mm 216600

Industrial control panels often need a reliable, easy-to-clean pushbutton that can withstand harsh environments. The Eaton 216600 is a flat pushbutton actuator designed for the Eaton M22 series, providing a green, non-illuminated momentary action. Its flat profile prevents accidental operation and simplifies cleaning, making it suitable for food processing, packaging, and other demanding applications.

Who is it for

Panel builders, maintenance technicians, and machine operators who require a robust, flat pushbutton actuator for 22.5 mm mounting holes. It is ideal for use in control panels, operator stations, and machinery where space is limited and reliability is critical.

Main features

• Flat actuator design for flush mounting and easy cleaning
• Green colour for clear visual indication
• Momentary (non-latching) operation
• Compatible with Eaton M22 contact blocks and LED elements
• High mechanical life: over 5 million operations
• Wide operating temperature range: -25 to +70 °C

Specifications

• Product Type: Pushbutton Actuator
• Actuator Design: Flat
• Actuator Colour: Green
• Operation Type: Momentary (Non-latching)
• Series: Eaton M22
• Mounting Diameter: 22.5 mm
• Front Protection Rating: IP66, IP67, IP69K
• Operating Temperature Range: -25 to +70 °C
• Storage Temperature Range: -40 to +80 °C
• Bezel Material: Plastic
• Actuator Material: Plastic
• Compatibility: Eaton M22 Contact Blocks and LED Elements
• Mechanical Life: > 5 million operations
• Illumination: Non-illuminated
• Number of Positions: 1

Tips

Pair this actuator with an Eaton M22 contact block for a complete pushbutton assembly. The flat design is particularly useful in applications where the button may be exposed to debris or requires frequent wiping.
