Eaton M22-PVLT valintakytkimen toimilaite, 2-asentoinen, lukittuva, musta 263469

The Eaton M22-PVLT selector switch actuator stands out with its maintained 2-position rotary action and black knob, designed for reliable manual control in industrial panels. Unlike momentary switches, it stays in the selected position, making it ideal for ON/OFF or 0/1 functions where the state must persist without continuous operator pressure.

Highlights

• 2-position maintained rotary actuator for stable switching states
• Black knob with 90° throw for clear visual indication
• Mounts in standard 22.5 mm panel cutouts
• Front protection rating IP66 for harsh environments
• Compatible with Eaton M22 series contact blocks (sold separately)

In daily use

This actuator is the front-end component of a modular control system. Install it into a 22.5 mm panel hole, attach a compatible Eaton M22 contact block, and you have a robust selector switch. The maintained action holds the selected position until manually changed, ensuring the controlled circuit remains in the desired state. The black knob provides a clear contrast against typical panel backgrounds, and the 90° rotation gives a positive feel.

Full specifications

• Number of positions: 2
• Switching action: Maintained (latching)
• Actuator type: Rotary knob
• Actuator colour: Black
• Mounting diameter: 22.5 mm
• Angle of throw: 90°
• Protection rating (front): IP66
• NEMA rating (front): NEMA 4X, 13
• Operating temperature: -25 to +70 °C
• Storage temperature: -40 to +80 °C
• Mechanical life: > 1,000,000 operations
• Material: Plastic actuator, metal bezel
• Illumination: Non-illuminated
• Contact block compatibility: Requires separate Eaton M22 series contact blocks
• Degree of protection (rear): IP20 (with contact blocks installed)
• Standards compliance: IEC/EN 60947, UL 508, CSA C22.2 No. 14

Final note

The Eaton M22-PVLT is a durable and precise actuator for industrial control applications, offering reliable maintained switching in a compact 22.5 mm format.
