Eaton P3-63/I4/SVB-SW 3-napainen pääkytkin 63 A 207344

This Eaton P3-63/I4/SVB-SW is a 3-pole main switch rated for 63 A, engineered for reliable load disconnection and emergency stop functions in industrial control panels. Its robust front-mount design with a red rotary handle and yellow locking ring ensures clear, safe operation.

Advantages

The switch offers a high switching capacity of 30 kW at 400 V AC (AC-23A), making it suitable for demanding motor loads. The handle can be locked with up to three padlocks, providing secure isolation during maintenance. With an IP65 front protection degree, it withstands dust and water jets, ideal for harsh environments.

Suitable for

• Main disconnection in machine control circuits
• Emergency stop applications requiring lockable isolation
• Industrial distribution boards and motor control centers

Key specifications

• Number of poles: 3
• Rated operational current: 63 A
• Rated operational voltage: 690 V AC
• Switching angle: 90°
• Terminal type: Screw terminals
• Mechanical endurance: >100,000 operations
• Operating temperature range: -25 to +50 °C

Recommendations

For installations requiring frequent switching and high safety, this switch provides dependable performance and compliance with IEC/EN 60947 standards.
