Eaton ZE-6 musta/valkoinen tehonrele (ZE-6)

The Eaton ZE-6 stands apart from generic auxiliary contact blocks by delivering a balanced 2NO+2NC contact arrangement in a compact, front-mountable housing. Built for the xStart series, it snaps directly onto DILM7–DILM38 contactors, giving you reliable signal and control switching without extra wiring or brackets.

Highlights

• 4-pole auxiliary contact block: 2 normally open + 2 normally closed
• Front mounting for quick, tool-free installation on Eaton DILM contactors
• Rated insulation voltage 690 V AC, impulse withstand 6 kV
• Silver alloy contacts for long electrical and mechanical life
• IP20 protection, screw terminals for secure wiring

In daily use

Whether you are expanding control logic, signalling load status, or interlocking circuits, the ZE-6 provides dependable switching in industrial environments. Its black/white colour scheme makes it easy to identify on the DIN rail, and the front-mount design means you can add or replace it without disturbing existing wiring. The screw terminals accept solid or stranded conductors, and the high mechanical endurance (>10 million operations) ensures years of service even in demanding automation tasks.

Full specifications

• Contact configuration: 2 NO + 2 NC
• Mounting type: Front mounting
• Compatibility: Eaton DILM contactors (DILM7 to DILM38)
• Rated operational current (AC-15, 230 V): 4 A
• Rated operational current (AC-15, 400 V): 3 A
• Rated operational current (DC-13, 24 V): 1 A
• Rated operational current (DC-13, 110 V): 0.5 A
• Rated insulation voltage (Ui): 690 V AC
• Rated impulse withstand voltage (Uimp): 6 kV
• Terminal type: Screw terminals
• Degree of protection: IP20
• Operating temperature range: -25 to +60 °C
• Storage temperature range: -40 to +80 °C
• Standards compliance: IEC/EN 60947-5-1, VDE 0660
• Contact material: Silver alloy
• Number of poles: 4-pole
• Series: xStart
• Colour: Black/White
• Mechanical life: > 10 million operations
• Electrical life: > 1 million operations

Final note

For engineers and panel builders who need a robust, no-nonsense auxiliary contact block, the Eaton ZE-6 delivers proven performance and easy integration with the DILM range.
