Finder 34.51.7.024.0010 miniatyyri-PCB-rele 24 V DC 6 A 1 CO SPDT

With a rated current of 6 A and a compact PCB-mount footprint, the Finder 34.51.7.024.0010 Miniature PCB Relay delivers reliable switching for demanding applications. Its 24 V DC coil and SPDT (1 CO) contact configuration make it a versatile choice for industrial control, automation, and building systems.

Overview

Part of Finder's 34 Series, this miniature PCB relay is engineered for high-density circuit board designs. It features a 1 CO (SPDT) contact set with silver-nickel (AgNi) contacts, capable of switching up to 6 A at 250 V AC or 30 V DC. The reinforced insulation provides a dielectric strength of 5000 V AC between coil and contacts, ensuring safety and reliability.

What stands out

• High switching capacity: 6 A / 250 V AC (1500 VA) and 6 A / 30 V DC (180 W)
• Wide operating temperature range: -40 °C to +85 °C
• Long mechanical life: 10 million operations
• Reinforced insulation with 5000 V AC coil-contact dielectric strength
• Compact PCB mounting with standard pin layout
• Approvals: VDE, UL, CSA

Technical details

• Coil voltage: 24 V DC
• Contact configuration: 1 CO (SPDT)
• Rated current: 6 A
• Contact material: AgNi (silver nickel)
• Max switching voltage: 400 V AC
• Max switching power: 1500 VA (AC1), 180 W (DC1)
• Electrical life at rated load: 100,000 cycles
• Mechanical life: 10,000,000 cycles
• Insulation type: Reinforced insulation
• Mounting type: PCB (through-hole)
• Terminal type: PCB pins

Our verdict

The Finder 34.51.7.024.0010 is a robust and dependable miniature PCB relay, ideal for applications requiring high switching power in a compact form factor. Its wide temperature range and long life make it a solid choice for industrial environments.
