Hager B800403 Tehalit BRN kaapelikanava 80x40mm 2m musta PVC

Electricians and network installers routing cables along walls or ceilings in commercial and residential buildings will find the Hager B800403 a reliable choice. This black PVC cable duct from the Tehalit BRN series measures 80 mm wide and 40 mm high, with a 2-meter length. The snap-on lid allows quick access for cable changes, while screw fixing ensures secure mounting. Made from self-extinguishing PVC, it is suitable for indoor electrical and data installations.

Key specifications

• Type: Cable Duct / Cable Trunking
• Series: Tehalit BRN
• Material: Polyvinyl Chloride (PVC)
• Colour: Black (RAL 9005)
• External Width: 80 mm
• External Height: 40 mm
• Length: 2000 mm
• Number of Compartments: 1
• Lid Type: Snap-on / Clip-on
• Mounting Type: Screw fixing
• Impact Resistance: IK07
• Operating Temperature Range: -5 °C to +60 °C
• Flammability Rating: Self-extinguishing, V-0 according to UL94
• Halogen-free: No
• UV Resistant: No

Why choose it

The snap-on lid simplifies cable installation and maintenance, while the robust PVC construction provides impact resistance and self-extinguishing properties for safety. The black finish blends with dark surfaces, and the 2-meter length reduces joints in long runs.

Ideal use cases

• Routing power and data cables in offices
• Concealing wiring in retail spaces
• Protecting cables in workshops and utility areas

Good to know

This duct is designed for indoor use only and is not UV resistant. It is halogen-free: No, so consider this in applications with strict smoke emission requirements. The duct is supplied without mounting screws.
