Hager LK750503 PVC pinta-asennettava kaapelikanava 75x50mm musta 2m

Exposed cables along walls and ceilings create clutter and safety hazards. The Hager LK750503 cable duct offers a clean, protective channel for routing power and data cables indoors. Its snap-on lid allows quick access for cable changes, while the black PVC construction blends with most interiors.

Who is it for

Electricians, facility managers, and DIY installers who need a durable, surface-mounted solution for organizing cables in offices, workshops, or residential spaces.

Main features

• Material: PVC (Polyvinyl Chloride)
• Colour: Black (RAL 9005)
• Dimensions: 75 mm width x 50 mm height x 2000 mm length
• Single compartment with snap-on lid
• Surface mounted
• Halogen-free: No
• Temperature range: -5°C to +60°C
• Impact resistance: IK07
• Self-extinguishing according to EN 60695-2-11 (glow-wire test 850°C)
• Usable cross-sectional area: approx. 30 cm²

Specifications

• Brand: Hager
• Model: LK750503
• MPN: LK750503
• EAN: 4012740104630
• Material: PVC
• Colour: Black
• Width: 75 mm
• Height: 50 mm
• Length: 2000 mm
• Mounting type: Surface mounted
• Number of compartments: 1
• Lid type: Snap-on / Clip-on
• Halogen-free: No
• IP protection class: IP40
• Temperature range: -5°C to +60°C
• Fire behaviour: Self-extinguishing according to EN 60695-2-11 (glow-wire test 850°C)
• Impact resistance: IK07
• Standards compliance: EN 50085-1, EN 50085-2-1
• Usable cross-sectional area: approx. 30 cm²
• Application area: Indoor cable management for power and data cables
• UV resistant: No

Tips

For a neat installation, cut the duct with a fine-tooth saw and deburr edges. Use appropriate screws or adhesive for mounting depending on the surface. The snap-on lid can be painted to match wall colour if desired.
