HAGER WAS1110BG pinta-asennettava SCHUKO-pistorasia itsesulkeutuvalla kansilevyllä, IP44, vaaleanharmaa

The HAGER WAS1110BG is a surface-mounted SCHUKO socket with a self-closing hinged lid, rated IP44 for protection against splashing water. Its light grey thermoplastic housing is halogen-free and impact resistant (IK05), making it suitable for demanding environments.

Overview

This 1-gang socket outlet provides a single SCHUKO (Type F) receptacle with screw terminals for conductors up to 2.5 mm². Designed for surface mounting, it operates at 250 V AC, 16 A, and 50/60 Hz. The hinged lid closes automatically to protect the contacts when not in use.

What stands out

• Self-closing hinged lid for enhanced safety and cleanliness
• IP44 rating – protected against water splashes from any direction
• Halogen-free thermoplastic housing with IK05 impact resistance
• Reliable screw terminals for secure wiring

Technical details

• Socket type: SCHUKO (Type F)
• Sockets quantity: 1
• Mounting type: Surface-mounted
• Rated voltage: 250 V AC
• Rated current: 16 A
• Frequency: 50/60 Hz
• Connection type: Screw terminals
• Terminal capacity: up to 2.5 mm² (rigid conductor)
• Material: Thermoplastic, halogen-free
• Colour: Light grey
• Protection class: IP44
• Impact resistance: IK05
• Operating temperature: -25 to +45 °C

Our verdict

A robust and practical choice for surface-mounted installations where splash protection and automatic lid closure are required.
