HEINRICH KOPP Schuko-pistorasia kansikannella, pinta-asennus, IP44, harmaa 137002003

Rated at 16 A and 250 V, this Schuko socket outlet handles demanding loads in damp or outdoor locations thanks to its IP44 splash-proof design.

Overview

The HEINRICH KOPP 137002003 is a single Schuko socket outlet with a hinged lid, intended for surface mounting. The grey thermoplastic housing and screw terminals suit fixed installations where a robust, splash-proof connection point is required.

What stands out

• IP44 rating protects against splashing water, making it suitable for outdoor and damp-room use.
• Hinged lid keeps the socket sealed when not in use.
• Halogen-free thermoplastic construction.
• Flexible cable entry from top, bottom, or rear.

Technical details

• Socket standard: Schuko (Type F)
• Number of sockets: 1
• Mounting type: Surface-mounted
• Rated voltage: 250 V AC
• Rated current: 16 A
• Frequency: 50/60 Hz
• Material: Thermoplastic
• Colour: Grey
• Connection type: Screw terminals
• Terminal capacity: up to 2.5 mm²
• Operating temperature: -25 °C to +40 °C
• Certification: VDE, CE

Our verdict

A dependable Schuko outlet for damp or outdoor installations, with a practical hinged lid and solid screw terminals.
