HellermannTyton 435-00082 push-in johdinliitin, 2-napainen, vihreä

Connecting solid conductors in junction boxes and lighting installations often means twisting wires, taping them, or using bulky terminal blocks. The HellermannTyton 435-00082 push-in wire connector eliminates that hassle: strip the wire, push it in, and the connection is secure. Its compact green housing fits easily into tight spaces, while the transparent design lets you visually confirm the conductor is fully inserted.

Who is it for

Electricians and installers who need fast, reliable connections for solid copper wires in building wiring, lighting, and small appliance applications. It is suitable for use in junction boxes, behind light fixtures, and inside equipment where space is limited.

Main features

• Push-in termination for solid conductors from 0.5 mm² to 2.5 mm²
• Rated for 450 V and 24 A, suitable for fixed installations
• Compact 2-pole design with green polycarbonate housing
• Operating temperature range -30 °C to +85 °C, with short-term maximum +105 °C
• Flammability rating UL94 V-0

Specifications

• Connector type: Push-in wire connector
• Number of poles: 2
• Colour: Green
• Rated voltage: 450 V
• Rated current: 24 A
• Conductor type: Solid (single-strand)
• Conductor cross-section: 0.5 mm² to 2.5 mm²
• Stripping length: 11 mm
• Housing material: Polycarbonate (PC)
• Contact material: Tinned copper
• Operating temperature: -30 °C to +85 °C
• Max. continuous operating temperature: +105 °C
• Flammability rating: UL94 V-0
• Approvals: VDE, ENEC, UL, CSA

Tips

Use a wire stripper to remove exactly 11 mm of insulation. Push the conductor straight in until it stops; the transparent housing allows you to verify full insertion. To release, twist and pull the wire while applying slight pressure.
