HELLERMANNTYTON HIS-3 3:1 lämpökutistesukka-valikoima, 127 osaa, musta 308-30615

Heat shrink tubing assortment with a 3:1 shrink ratio, supplied in a convenient box. The set contains 127 pieces of black cross-linked polyolefin tubing in eight different diameters, each 100 mm long.

Advantages

Cross-linked polyolefin provides good electrical insulation and mechanical protection. The 3:1 shrink ratio allows the tubing to conform to irregular shapes and provides a tight seal. The material is self-extinguishing and meets UL224 VW-1 requirements.

Suitable for

• Electrical insulation and strain relief
• Bundling and marking of wires and cables
• Protection against abrasion and chemicals
• Applications requiring a compact, organised assortment

Key specifications

• Shrink ratio: 3:1
• Material: Cross-linked polyolefin
• Colour: Black
• Number of pieces: 127
• Tube length: 100 mm
• Operating temperature range: -55°C to +135°C
• Minimum shrink temperature: +90°C
• Dielectric strength: >20 kV/mm
• Flame retardancy: Self-extinguishing (UL224 VW-1)
• Halogen-free: No
• Approvals: UL224 VW-1, CSA
• Included expanded diameters: 1.5 mm, 2.5 mm, 3.5 mm, 5.0 mm, 6.0 mm, 8.0 mm, 10.0 mm, 13.0 mm
• Included recovered diameters: 0.5 mm, 0.8 mm, 1.2 mm, 1.6 mm, 2.0 mm, 2.5 mm, 3.0 mm, 4.0 mm
• Typical wall thickness (recovered): 0.45 mm - 0.8 mm (varies by size)

Recommendations

Use a heat gun set to at least 90°C for uniform shrinking. Store in a dry place away from direct sunlight.
