HellermannTyton HIS-3 kutistesukka, 6 mm halkaisija, 170 mm pituus, musta, polyolefiini, 3:1 suhde

HellermannTyton presents the HIS-3 heat shrink tubing, a high-performance solution for insulation, protection, and strain relief of electrical connections and cables. This black, cross-linked polyolefin tubing offers a 3:1 shrink ratio, expanding to 6mm and recovering to 2mm, ensuring a tight, secure fit over a variety of components. With a length of 170mm, it is ideal for applications requiring reliable sealing and mechanical protection.

Advantages

The HIS-3 series provides excellent dielectric strength and flame retardancy, meeting UL224 VW-1 and CSA C22.2 No. 198.1 standards. Its halogen-free composition and RoHS compliance make it an environmentally friendly choice. The tubing operates effectively in temperatures ranging from -55°C to +125°C, with a minimum shrink temperature of +90°C, ensuring durability in harsh conditions.

Suitable for

• Insulating electrical connections and terminals
• Protecting cables from abrasion and environmental stress
• Strain relief for wire bundles
• Color-coding and identification of wires

Key specifications

• Product Type: Heat Shrink Tubing
• Series: HIS-3
• Material: Cross-linked Polyolefin
• Colour: Black
• Expanded Diameter: 6 mm
• Recovered Diameter: 2 mm
• Shrink Ratio: 3:1
• Length: 170 mm
• Operating Temperature: -55 °C to +125 °C
• Minimum Shrink Temperature: +90 °C
• Dielectric Strength: 20 kV/mm
• Flammability Rating: UL94 V-2
• Halogen-free: Yes
• RoHS Compliant: Yes
• Standards Met: UL224 VW-1, CSA C22.2 No. 198.1
• Recovered Wall Thickness: 0.50 mm (approx.)

Recommendations

For best results, use a heat gun or hot air blower to evenly shrink the tubing. Ensure the tubing is fully recovered and adheres snugly to the substrate. Store in a cool, dry place away from direct sunlight.
