Hikvision DS-220AZJ-130-BA virtalähde 12V 1,5A 18W musta

The Hikvision DS-220AZJ-130-BA is a high-quality power adapter designed to provide reliable 12V DC power to Hikvision CCTV cameras, DVRs, NVRs, and other compatible 12V DC devices. With an output of 1.5A (18W), this adapter ensures stable performance for your security equipment.

Advantages

This power adapter features a compact design with a C8 (Figure-8) AC input connector and a 5.5mm x 2.1mm barrel plug with center positive polarity. It includes comprehensive protection against over-voltage, over-current, and short circuits, ensuring the safety of your connected devices. The Level VI efficiency rating guarantees energy-saving operation.

Suitable for

• Hikvision CCTV cameras
• Hikvision DVRs and NVRs
• Any 12V DC device requiring up to 1.5A

Key specifications

• Input: AC 100-240V, 50/60Hz
• Output: DC 12V, 1.5A, 18W
• Connector: 5.5mm x 2.1mm barrel plug, center positive
• AC input: C8 (Figure-8) – power cord not included
• Protection: Over-voltage, over-current, short-circuit
• Efficiency: Level VI
• Operating temperature: -10°C to 40°C
• Housing: ABS plastic, black
• Certifications: CE, FCC, RoHS

Recommendations

For optimal performance, use only with compatible Hikvision devices. Ensure the total current draw of connected equipment does not exceed 1.5A. A separate C7/C8 power cord is required for AC connection.
