I/O-peitelevy Supermicro MCP-260-00085-0B metalli musta

1U I/O shield compatible with Supermicro X10SDV-F and X10SDV-TLN4F motherboards, designed to fit in CSE-510, CSE-505 and CSE-504 server chassis. The Supermicro MCP-260-00085-0B is a single-piece metal I/O shield in black finish that protects rear motherboard ports and helps maintain proper alignment and connectivity within compact 1U server enclosures.

Advantages

The metal construction provides durable protection for rear I/O ports while the black finish offers a uniform appearance inside matching chassis. Sold individually, this MCP-260-00085-0B I/O shield is sized specifically for 1U server layouts and helps prevent dust ingress and port damage during installation and operation.

Suitable for

• Supermicro X10SDV-F motherboard
• Supermicro X10SDV-TLN4F motherboard
• CSE-510 rack chassis
• CSE-505 rack chassis
• CSE-504 rack chassis

Key specifications

• Manufacturer: Supermicro
• Model / MPN: MCP-260-00085-0B
• Finish: Metal, black
• Form factor: 1U I/O shield
• Sold as: Single unit
• Compatible with: X10SDV-F / X10SDV-TLN4F and CSE-510/505/504 chassis

How to use

Align the I/O shield with the rear cutout of the 1U chassis and the motherboard’s rear ports, then press gently until the shield snaps into the chassis retaining clips. Install the motherboard so that its rear connectors pass through the corresponding openings in the shield, ensuring a flush fit to maintain port alignment and grounding.

Recommendations

Use this I/O shield when installing or replacing an X10SDV-F or X10SDV-TLN4F motherboard in compatible CSE-510/505/504 chassis. Ensure the chassis is powered off and grounded during installation and verify that the shield fits flush to avoid obstructing port connections.
