INKOVIDEO INKO-PRO-PDK-1 ammattimainen PTZ-joystick-ohjain

The INKOVIDEO INKO-PRO-PDK-1 is a professional-grade PTZ joystick controller designed for precise control of PTZ cameras in broadcast, security, and live event environments. Featuring a 3-axis joystick and support for multiple control interfaces and protocols, it offers seamless integration with a wide range of camera systems.

Advantages

Versatile control with RS-232, RS-485, RS-422, and IP (Ethernet) interfaces. Supports VISCA, Pelco-D, Pelco-P, and ONVIF protocols for broad compatibility. Ergonomic 3-axis joystick with silicone backlit buttons for comfortable operation in low-light conditions. LCD display with backlight provides clear status feedback. Capable of controlling up to 255 cameras with up to 255 preset positions each.

Suitable for

• Professional video production studios
• Security and surveillance control rooms
• Live event and broadcast environments
• Educational and corporate AV systems

Key specifications

• Control Interface: RS-232, RS-485, RS-422, IP (Ethernet)
• Supported Protocols: VISCA, Pelco-D, Pelco-P, ONVIF
• Joystick Type: 3-axis (Pan, Tilt, Zoom)
• Controllable Cameras: Up to 255
• Preset Positions: Up to 255 per camera
• Display: LCD with Backlight
• Baud Rate Range: 2400, 4800, 9600, 19200, 38400 bps
• Communication Distance (RS-485): Up to 1200 m
• Power Supply: DC 12V / 2A
• Connectivity Ports: 1x RJ45 (Ethernet), 1x RS-232 (DB9), 1x RS-485/422 (Terminal Block)
• Material: High-quality ABS Plastic, Metal Base
• Operating Temperature: -10°C to 50°C
• Operating Humidity: 10% to 90% (non-condensing)
• Control Functions: Pan, Tilt, Zoom, Focus, Iris, Exposure, White Balance, OSD Menu, Preset Call/Set, Tour, Scan
• Button Type: Silicone with Backlight
• Firmware Update: Yes, via USB or Ethernet

Recommendations

For optimal performance, use a shielded CAT5e or higher Ethernet cable for IP connections and a twisted-pair cable for RS-485. Ensure the power supply is rated at DC 12V / 2A. Compatible with most PTZ cameras supporting VISCA, Pelco-D, Pelco-P, or ONVIF protocols.
