Kaapeliliitin EFB Elektronik 29011.1

The EFB Elektronik 29011.1 is a D-sub 15-pin female wire connector in black, designed for compact and reliable signal connections in electronic assemblies. With a small footprint (39.2 mm width, 12.6 mm depth, 20.6 mm height) it fits into constrained panel or enclosure spaces while providing a stable mating interface for 15-pin D-sub applications. The connector is supplied as a single piece per pack and is intended for wiring applications where a durable female D-sub contact is required.

Advantages

This D-sub 15-pin female wire connector offers a compact form factor that saves space in tight installations and enclosures. The black housing provides discreet visual integration into equipment panels. Its standard 15-pin configuration supports widely used signal pinouts and ensures compatibility with mating D-sub plugs. The connector is built for repeated mating cycles and stable electrical contact, supporting reliable long-term operation in electronic systems.

Suitable for

• PC and industrial control interfaces requiring 15-pin D-sub connections
• Signal wiring in measurement and instrumentation equipment
• Repair or replacement of female D-sub connectors in electronic devices
• Small enclosures and custom electronics projects with limited space

Key specifications

• Connector type: D-sub female, 15 pins
• Housing color: black
• Dimensions (W × D × H): 39.2 mm × 12.6 mm × 20.6 mm
• Pack quantity: 1 piece
• Mounting/wire termination: wire connector style suitable for cable termination (refer to assembly instructions for exact method)

How to use

Prepare the cable conductors according to the chosen termination method and the pinout required for your application. Insert and secure each conductor into the appropriate contact of the female D-sub connector following standard wiring practices and any provided assembly guidance. After wiring, verify continuity and correct pin mapping before mating the connector with a corresponding 15-pin male D-sub plug. Ensure that the connector is mounted or supported to avoid strain on the cable and contacts.

Recommendations

For reliable performance, use this connector within its intended environmental and electrical conditions, avoid excessive mechanical stress on the housing and contacts, and perform a continuity check after installation. Use compatible mating plugs and secure mounting to reduce the risk of intermittent connections.
