Kaapelisarja RAID-ohjaimelle Fujitsu PY-CBS108 — HDD/SAS-kaapelikokoonpano

Cable kit for RAID controller Fujitsu PY-CBS108 — HDD/SAS cable assembly is a factory-made cabling solution designed to connect hard drives and SAS devices to a Fujitsu RAID controller. The assembly provides the necessary external and internal cable runs for correct signal routing and reliable disk connectivity in server environments. It is intended for maintenance, upgrades, or replacements in data centers and enterprise server racks where consistent SAS link performance and straightforward installation are required.

Advantages

This cable assembly is factory-terminated to ensure consistent electrical characteristics and secure connector fit. It reduces installation time compared with assembling separate cables and minimizes potential signal integrity issues caused by improvised or non-matching connectors. The kit is compatible with standard server drive configurations and is intended to preserve RAID controller performance by providing proper impedance and shielding for SAS connections.

Suitable for

• Connecting HDDs or SAS devices to a Fujitsu RAID controller in rack or tower servers
• Server maintenance and replacement of worn or damaged cabling
• Upgrading storage backplanes or drive enclosures in enterprise environments
• Data center installations requiring reliable SAS connectivity and predictable signal behavior

Key specifications

• Cable type: SAS/HDD interconnect assembly suitable for RAID controller connections
• Connector types: factory-terminated connectors matching Fujitsu RAID controller and drive interface requirements
• Application: supports internal and external SAS link routing for storage arrays and drive enclosures
• Construction: shielded multi-conductor cable to maintain signal integrity at SAS data rates
• Use environment: designed for server and data center installations with standard operating conditions

How to use

Install the cable assembly by aligning connectors with the RAID controller ports and the target drive or backplane connectors, then engage latches or screws as provided on each connector. Route the cable to avoid sharp bends and proximity to high-power or noisy components to maintain signal integrity. Verify connection status through the RAID controller management interface and test attached drives for proper detection before returning the server to production use.

Recommendations

For reliable operation, use the cable assembly in environments that meet standard server temperature and humidity ranges, avoid excessive bending radii at connector ends, and replace the assembly if connectors show wear or if intermittent link errors occur. If changes to drive or controller models are made, confirm connector compatibility before installation.
