Kindermann WPaMIX-T seinäpaneeli XLR/RCA äänenvoimakkuus/mikseri

The Kindermann WPaMIX-T is a passive audio wall mixer and attenuator designed for professional AV installations in conference rooms, classrooms, and meeting spaces. It provides a clean, flush-mount solution for integrating audio sources into a wall panel, offering volume control and passive mixing of one balanced XLR and two unbalanced RCA inputs.

Advantages

Passive operation eliminates the need for external power, simplifying installation and reducing costs. The compact 85x85mm front plate fits standard European flush-mount boxes, ensuring a seamless look. High-quality plastic construction in white (RAL 9010) blends with any interior.

Suitable for

• Conference rooms requiring simple audio mixing and volume control
• Classrooms and presentation systems with multiple audio sources
• Meeting spaces where a discreet, wall-mounted audio interface is needed

Key specifications

• Input Connectors: 1x XLR (female), 2x RCA (stereo pair)
• Output Connector: 3-pin screw terminal block
• Audio Functionality: Volume control, Passive mixing
• Input Signal Type: Analog Line-Level Audio
• Mounting Type: Flush-mount wall installation
• Compatible Installation Box: Standard European flush-mount box (e.g., 60mm diameter)
• Panel Material: High-quality plastic
• Panel Color: White (RAL 9010 or similar)
• Controls: 1x Rotary potentiometer (volume)
• Power Requirement: Passive (no external power supply needed)
• Application Area: Conference rooms, classrooms, meeting spaces, presentation systems
• Number of Inputs: 3 (1x balanced XLR, 2x unbalanced RCA)
• Number of Outputs: 1 (balanced/unbalanced via terminal block)
• Product Type: Passive Audio Wall Mixer/Attenuator
• Front Plate Dimensions (W x H): 85 x 85 mm
• Installation Depth: Approx. 45 mm
• Signal Processing: Analog, Passive
• Frequency Response: 20 Hz - 20 kHz (typical for passive audio)

Recommendations

For optimal performance, use high-quality shielded cables for XLR and RCA connections. Ensure the installation box is properly grounded. This panel is ideal for integrating microphones and line-level sources into a single output.
