Kosketusvalokytkin Avatto TS60-EU-W4 ZigBee langaton kosketusseinäkytkin, EU-versio

Avatto ZTS60 is a 4-gang touch Zigbee light switch designed for smart home lighting control. It supports Zigbee 3.0 and connects via a compatible Zigbee gateway, enabling remote control, scheduling and automation through the AVATTO app. The switch combines touch control with app-based management for both indoor and outdoor lighting circuits.

Advantages

The switch is made of flame-retardant PC for increased safety and longevity. It supports a maximum load of 800 W per circuit and a rated current of 10 A, suitable for standard home installations. Easy pairing and configuration via the AVATTO app allow quick setup and integration with other smart home devices.

Key specifications

• Manufacturer: Avatto
• Model: ZTS60
• Type: Intelligent light switch
• Version: 4-gang
• Power supply: AC 100–240 V, 50/60 Hz
• Maximum load: 800 W per circuit (resistive)
• Maximum current: 10 A
• Communication protocol: Zigbee 3.0
• Standby power consumption: 0.1 mA
• Housing material: Flame retardant PC
• Dimensions: 80 × 80 mm
• Wiring: L (phase), N (neutral), L1 (load 1)

How to use

Install the switch by connecting wires according to the marking: L for phase, N for neutral and L1 for the first load; repeat wiring for each circuit as required. After power is applied, press and hold the device button for 5 seconds until the backlight flashes to enter pairing mode. Add the switch in the AVATTO app and follow on-screen instructions. Use the app to control circuits in real time, create schedules and set automations. The device requires a Zigbee gateway and a 2.4 GHz Wi‑Fi network for remote features.

Recommendations

Use the switch within the specified electrical limits (max 800 W per circuit, 10 A). Install according to local electrical codes and, if unsure, hire a qualified electrician. Ensure a compatible Zigbee gateway and a stable 2.4 GHz network for full functionality.
