Lattialevy EFB Elektronik PRO-MOD06A.TS

The EFB Elektronik PRO-MOD06A.TS bottom plate is a steel base plate intended for rack-mounted equipment and similar installations. With a compact footprint of 380 mm x 380 mm and a corrosion-resistant black finish, this plate provides a stable and durable foundation for electronics, power supplies, instruments and other components used in industrial, laboratory or AV rack systems.

Advantages

Constructed from robust steel, the bottom plate resists deformation under load and offers mechanical protection for mounted devices. The black surface finish reduces visible wear and integrates visually with standard rack interiors. Its square dimensions deliver a consistent support area that simplifies placement and alignment of equipment within a rack or cabinet. The product is designed for reliable long-term use in environments where stability and strength are required.

Suitable for

• Mounting power supplies and transformers in 19" or custom rack enclosures
• Supporting electronic modules, controllers and small instruments
• Use as a replacement or reinforcement plate in server cabinets and industrial racks
• Applications requiring a stable, flat base for bolting or screwing equipment

Key specifications

• Material: steel
• Finish: black protective coating
• Dimensions (W x D): 380 mm x 380 mm
• Form factor: square bottom plate for rack installation

How to use

Place the bottom plate on the floor of the rack or cabinet and align it to the rack rails or mounting points. Secure the plate using appropriate fasteners through the available mounting holes or by bolting it to the cabinet base, ensuring even torque to avoid distortion. Mount equipment onto the plate using screws or brackets compatible with the device mounting pattern. Verify that weight distribution is balanced and that cables have sufficient clearance to prevent strain.

Recommendations

For safe and long-lasting installation, use corrosion-resistant fasteners and, where applicable, insulating washers to prevent galvanic corrosion between dissimilar metals. Check load capacity of the rack and distribute heavy components evenly. Regularly inspect the plate and fasteners for signs of corrosion or loosening, especially in humid or industrial environments.
