LogiLink 2x2 HDMI 2.0b -matriisikytkin 4K/60Hz EDID:llä, HDCP 2.2, HDR, downscaler

Handle two 4K HDR sources on two displays at once with full matrix switching, 18 Gbps bandwidth, and a built-in downscaler that feeds 1080p screens from 4K signals.

Overview

The LogiLink HD0039 is a 2x2 HDMI matrix switch that routes any of two HDMI sources to either or both of two HDMI displays independently. Supporting HDMI 2.0b and HDCP 2.2, it passes through 4K UHD at 60 Hz with HDR10, HLG, and Dolby Vision, plus 12-bit Deep Color and high-resolution audio formats. Advanced EDID management and a downscaler ensure compatibility with mixed-resolution setups, while push-button and IR remote control make switching effortless.

What stands out

• True 2x2 matrix: send either input to either or both outputs simultaneously
• 4K/60 Hz with HDR10, HLG, and Dolby Vision for stunning picture quality
• Built-in downscaler converts 4K to 1080p for legacy displays
• Advanced EDID management prevents resolution and audio handshake issues
• HDCP 2.2 compliant for protected 4K content
• 18 Gbps bandwidth supports full 4K/60 4:4:4 color
• Metal housing with LED status indicators for reliable operation

Technical details

• HDMI Standard: HDMI 2.0b
• HDCP Version: HDCP 2.2 (backward compatible with 1.4)
• Maximum Resolution: 4K Ultra HD (3840x2160)
• Maximum Refresh Rate: 60 Hz at 4K
• Input Ports: 2x HDMI Type A Female
• Output Ports: 2x HDMI Type A Female
• Data Transfer Rate: 18 Gbps
• HDR Support: HDR10, HLG, Dolby Vision
• EDID Management: Yes (Advanced EDID)
• Downscaler Function: Yes (4K to 1080p)
• Color Depth: 8/10/12-bit Deep Color
• Audio Formats: LPCM 7.1CH, Dolby TrueHD, DTS-HD Master Audio
• Control Method: Push Button, IR Remote Control
• Power Supply: DC 5V/1A (external adapter)
• Housing Material: Metal
• LED Indicators: Yes (for input/output status)
• Operating Temperature: 0°C to 40°C
• Compliance: CE, FCC, RoHS

Our verdict

The LogiLink HD0039 is a versatile and robust matrix switch that delivers exceptional 4K HDR performance with the flexibility to handle mixed-resolution setups. Its downscaler and EDID management make it a reliable choice for both modern and legacy displays.
