Märklin 046805 H0 AC pylväsvaunu Rlmms 580 Deutsche Bundesbahn aikakausi IV pylväillä

With a length over buffers of 157 mm and a die-cast metal chassis, this Märklin H0 flatcar delivers robust performance on 3-rail AC layouts. The Rlmms 580 design features removable stanchions and a detailed underframe, reflecting Deutsche Bundesbahn Era IV operations.

Overview

The Märklin 046805 is an H0 scale (1:87) Rungenwagen (flatcar with stanchions) for the Märklin AC 3-rail system. It is decorated for the Deutsche Bundesbahn (DB) as wagon designation Rlmms 580, representing Era IV (1965-1990). The model features NEM coupler pockets with a close coupling mechanism (KKK) and includes standard close couplers. The chassis is die-cast metal, while the body is high-quality plastic. The minimum operating radius is 360 mm (Märklin R1).

What stands out

• Removable stanchions allow flexible load configurations.
• Detailed underframe enhances realism.
• Close coupling mechanism ensures prototypical spacing between wagons.
• Die-cast metal chassis provides stability and weight for reliable running.

Technical details

• Scale: H0 (1:87)
• Railway system: Märklin AC (3-rail)
• Railway company: Deutsche Bundesbahn (DB)
• Wagon type: Rungenwagen (flatcar with stanchions)
• Wagon designation: Rlmms 580
• Era: IV (1965-1990)
• Coupling: NEM pockets with close coupling mechanism (KKK), standard close couplers included
• Chassis material: die-cast metal
• Body material: high-quality plastic
• Length over buffers: 157 mm
• Minimum radius: 360 mm
• Special features: removable stanchions, detailed underframe
• Included load: simulated logs (may vary by production run)

Our verdict

A well-detailed and robust flatcar for Märklin AC enthusiasts, ideal for Era IV freight trains.
