Lähestymislukija ATLO-KR-522 RFID 125 kHz Wiegand 26/34 IP65 musta

RFID proximity reader with a 125 kHz operating frequency, delivering reliable contactless identification for access control systems. It reads EM4100 compatible cards and tags at a range of up to 10 cm, ensuring quick and convenient entry for authorized personnel.

Advantages

The ATLO-KR-522 combines robust construction with flexible integration. Its IP65-rated ABS housing protects against dust and water jets, making it suitable for both indoor and outdoor installations. Selectable Wiegand 26 or 34 output ensures compatibility with a wide range of controllers, while the built-in buzzer and red/green LED provide clear user feedback.

Suitable for

• Office and commercial building access control
• Residential complexes and gated communities
• Industrial facilities requiring durable readers
• Time and attendance systems

Key specifications

• Reading technology: RFID proximity, 125 kHz
• Supported cards: EM4100 compatible (Unique)
• Reading range: up to 10 cm
• Output: Wiegand 26 / Wiegand 34 (selectable)
• Power supply: 9 - 15 V DC, max 100 mA
• Ingress protection: IP65
• Operating temperature: -20°C to 60°C
• Relative humidity: 10% to 90% non-condensing
• Housing material: ABS plastic, black
• Mounting: surface mount
• Cable length: approx. 15 cm

Recommendations

For optimal performance, mount the reader on a flat, non-metallic surface away from sources of electromagnetic interference. Use a regulated 12 V DC power supply and ensure the Wiegand output matches your controller's input configuration.
