NOARK muovinen jakokeskus PT 36M 3x 12M 460x273x68

The NOARK PT 36M stands apart from conventional enclosures by combining a spacious 36-module capacity with a compact, surface-mounted plastic body that weighs just 1.4 kg. Its transparent polycarbonate door and pre-punched knockouts turn routine installations into quick, inspection-friendly work—no metal cutting, no guesswork.

Highlights

• 36 modules across 3 rows of 12 DIN slots
• ABS body with transparent PC door for instant visual checks
• IP40 and IK07 rated for indoor durability
• Halogen-free, UV-resistant, and glow-wire tested to 650 °C
• Includes N+PE terminal blocks and pre-punched cable entries

In daily use

Mount the PT 36M on any flat surface and snap in standard DIN rail devices. The transparent door lets you verify breaker status without opening the enclosure, while the knockouts accept common cable glands or conduits. With an operating range of -25 °C to +60 °C and a rated insulation voltage of 500 V, it handles residential and light commercial distribution reliably.

Full specifications

• Brand: NOARK
• Model: PT 36M
• MPN: 1101079
• EAN: 3838895571490
• Installation type: Surface-mounted
• Number of modules: 36
• Number of rows: 3
• Modules per row: 12
• Enclosure material: ABS plastic
• Door material: Transparent polycarbonate
• IP protection rating: IP40
• IK impact protection rating: IK07
• Colour: White (RAL 9003)
• Glow wire test temperature: 650 °C
• Operating temperature range: -25°C to +60°C
• Rated insulation voltage (Ui): 500 V
• Rated impulse withstand voltage (Uimp): 4 kV
• Halogen free: Yes
• UV resistant: Yes
• Terminal blocks included: N+PE (Neutral and Earth)
• Standards compliance: EN 60670-24
• Cable entry: Pre-punched knockouts

Final note

The NOARK PT 36M is a practical choice for electricians who need a reliable, transparent enclosure for DIN rail devices in residential and light commercial settings. Its robust construction and thoughtful features ensure long-term performance and easy maintenance.
