OBO BETTERMANN Rehau RAUTRIGO kaapelikanavan ulkokulma 35x35mm liikennevalkoinen 6131153

When cable ducts meet at a 90-degree angle on an outside corner, a simple straight section cannot make the turn. This external corner piece solves that by providing a ready-made, snap-on fitting that keeps the installation neat and the cables protected.

Who is it for

Electricians and installers working with the Rehau RAUTRIGO cws cable duct system, particularly in residential or commercial buildings where surface-mounted wiring needs to change direction around an external corner.

Main features

• External corner fitting for 35 x 35 mm cable ducts
• Snap-on / clip-on mounting for quick installation
• Made of PVC-U for durability
• Traffic white (RAL 9010) colour matches standard duct sections
• Part of the Rehau RAUTRIGO cws system

Specifications

• Product type: Cable Duct External Corner
• System series: Rehau RAUTRIGO cws
• Compatible channel dimensions (W x H): 35 x 35 mm
• Material: PVC-U
• Colour: Traffic White (RAL 9010)
• Mounting method: Snap-on / Clip-on
• Application: Cable management, electrical installations
• Fire behaviour: Self-extinguishing, flame-retardant
• Glow-wire test: 850 °C according to EN 60695-2-11
• Operating temperature range: -5 °C to +60 °C
• Halogen-free: No
• UV resistance: Limited (for indoor use)
• Standards compliance: DIN EN 50085-1, DIN EN 50085-2-1
• Package quantity: 1 piece
• Insulation class: Class II
• Impact resistance: IK07
• Protection degree: IP20

Tips

Ensure the duct ends are cut square and clean before snapping on the corner piece. For a secure fit, align the corner with the duct profile and press firmly until it clicks into place.
