OBO Bettermann ZA 60-DE tiiviste kojerasioille, ilmatiivis, harmaa, 10 kpl (2003719)

Ceiling outlet box made of halogen-free polypropylene in white (RAL 9010). The box provides seven elastic membrane cable entries for cables up to 15 mm diameter and is suitable for flush-mounted or surface-mounted installation in dry interiors.

Advantages

Elastic membranes seal around cables without additional grommets, saving installation time. The halogen-free material does not emit corrosive gases in the event of fire. Flame retardant and glow-wire tested to 650 °C for added safety.

Suitable for

• Ceiling installations in dry indoor areas
• Flush-mounted or surface-mounted applications
• Cable routing with up to seven entries

Key specifications

• Material: Polypropylene (PP)
• Colour: White (RAL 9010)
• Outer diameter: 100 mm
• Depth: 34.5 mm
• Number of cable entries: 7
• Cable entry type: Elastic membrane
• Max. cable entry diameter: 15 mm
• Protection class: IP20
• Halogen-free: Yes
• Glow-wire test: 650 °C
• Operating temperature: -5 °C to +60 °C
• Mounting: Flush-mounted, surface-mounted
• Rated insulation voltage: 400 V AC
• Application area: Dry interiors
• Standard conformance: DIN EN 60670-1 (VDE 0606-1)
• Pack size: 10 pieces
• Flame retardant: Yes
• UV resistant: No

Recommendations

Use this outlet box for neat and safe cable distribution in residential and commercial ceilings. The elastic membranes ensure a tight seal, and the halogen-free material contributes to fire safety.
