PRODIG-TECH GL-SMART-2 maalinpaksuusmittari 0-2000 µm

The PRODIG-TECH GL-SMART-2 is a professional paint thickness gauge designed for accurate measurement of coating thickness on ferrous and non-ferrous substrates. With a measurement range of 0 to 2000 µm and automatic substrate detection, this device is ideal for automotive, industrial, and quality control applications.

Advantages

High accuracy of ±10 µm + 2% of reading ensures reliable results. The integrated spherical tip probe allows precise measurements on curved surfaces. Automatic calibration with included Fe and Al plates simplifies setup. The backlit LCD display and built-in LED flashlight enable use in low-light conditions. Sound signaling and HOLD function enhance usability.

Suitable for

• Automotive paint inspection
• Industrial coating thickness measurement
• Quality control in manufacturing
• Marine and aerospace applications

Key specifications

• Measurement Range: 0–2000 µm (0–78.7 mils)
• Resolution: 10 µm (0–500 µm), 50 µm (500–2000 µm)
• Accuracy: ±10 µm + 2% of reading
• Substrates: Steel (Fe), Galvanized Steel (Fe+Zn), Aluminum (Al)
• Probe: Integrated, spherical tip
• Display: Backlit LCD
• Power: 2x AAA batteries (not included)
• Memory: 30 measurements
• Auto power off: after 2 minutes

Recommendations

For best results, calibrate the gauge before each use using the provided calibration plates. Ensure the substrate is clean and free of debris. Store in a dry environment when not in use.
