PULSAR AWZ529 relemoduuli SPDT 10-16V DC 2A

The PULSAR AWZ529 is a compact and reliable relay module designed for use in security systems, access control, CCTV, and general-purpose switching applications. Featuring a single-pole double-throw (SPDT) relay with screw terminals and an LED status indicator, this module offers easy installation and clear operational feedback.

Advantages

This relay module provides a robust switching solution with a wide input voltage range of 10-16V DC, making it compatible with many power supplies. The screw mount design ensures secure attachment, while the LED indicator allows for quick visual confirmation of relay status. With a maximum contact current of 2A DC and 0.5A AC, it is suitable for low-power switching tasks.

Suitable for

• Security systems and alarm panels
• Access control systems
• CCTV camera switching
• General-purpose low-voltage switching

Key specifications

• Relay Type: SPDT (Single Pole Double Throw)
• Number of Relays: 1
• Input Voltage (Coil): 10V - 16V DC
• Contact Configuration: Normally Open (NO), Normally Closed (NC)
• Max Contact Current (DC): 2A
• Max Contact Voltage (DC): 30V DC
• Max Contact Current (AC): 0.5A
• Max Contact Voltage (AC): 125V AC
• Current Consumption (Coil): 25mA
• Mounting Type: Screw Mount
• Connection Type: Screw Terminals
• Status Indicator: LED
• Operating Temperature: -10°C to +40°C

Recommendations

For optimal performance, ensure the input voltage is within the specified range and the load does not exceed the maximum ratings. Use appropriate gauge wire for screw terminals and secure the module firmly to a mounting surface.
